Education: Don’t believe every thing you read.

#MS Research. Animal studies trend to go more trial-like.

I was asked this week what sources of information do you trust. I said definitely not the media…..and the best judgement is to learn the science and read the papers yourself. However, this is not easy especially if you learn bad practises.

There has been a trend to make animal studies more like clinical studies. Whilst the intention is to improve the rigour of experimental design and reporting, unfortunately it can go the other way. Once having a statistical value of P>0.05 (means is you did experiment twenty times, by chance this result would happen) was considered a failure experimentally.

However, in clinical studies, which are often small in nature, there has been a tendency for people to say that when P<0.1 there is a trend rather than say there was no statistically significant difference. So being positive when it really is negative.

OK you can reject a null hypothesis when there is in fact a real biological difference or accept a null hypothesis that there is no difference between observations when there is a biological difference these are called Type I and Type II errors.

Null hypothesis (H0) is
Valid/True Invalid/False
Judgement of Null Hypothesis (H0) Reject Type I error
False Positive
Correct inference
True Positive
Accept (fail to reject) Correct inference
True Negative
Type II error
False negative

Now more human trial-like animal studies arrives in Nature Journals, leading us into more bad science:-).

So in a recent paper it states about statistical analysis

Unless stated otherwise, non-paired Student’s t-tests were performed for statistical analysis. P values <0.05 are indicated by *P values <0.005 by **P values <0.1 were considered as a trend”.
Maybe the referee is a clinician, who else would accept this?, and now failure becomes a trend:-(

Maybe power the study to get the answer, but we know Nature Journals have not been good at this

Two years later: journals are not yet enforcing the ARRIVE guidelines on reporting standards for pre-clinical animal studies. Baker D, Lidster K, Sottomayor A, Amor S. PLoS Biol. 2014 Jan;12(1):e1001756. There is growing concern that poor experimental design and lack of transparent reporting contribute to the frequent failure of pre-clinical animal studies to translate into treatments for human disease. In 2010, the Animal Research: Reporting of In Vivo Experiments (ARRIVE) guidelines were introduced to help improve reporting standards. They were published in PLOS Biology and endorsed by funding agencies and publishers and their journals, including PLOS, Nature research journals, and other top-tier journals. Yet our analysis of papers published in PLOS and Nature journals indicates that there has been very little improvement in reporting standards since then. This suggests that authors, referees, and editors generally are ignoring guidelines, and the editorial endorsement is yet to be effectively implemented.

When analysed, less than 5% of animal studies do a power calculation. This is because animal studies that are published are invariably positive as there is a publication bias of positive results.

In that paper we asked whether the data was analysed incorrectly.

EAE scoring is an scale of limp tail, limp legs and a random score is given to these features this type of data is not continuous this is called non parametric data and you should use non parametric statistics to analyse. Other data like height are continuous such as there are measures between 1m and to 2m say such as 1.5m, 1.24m, 1.23m. EAE data on the whole should not be analysed with parametric (e.g. T tests) but should use non-parametric data. We looked in the literature and found that in many cases parametric statistics are wrongly used. This occurred in the top journal (These have a high impact factor)

Overall it was about half the time in Journals, but in the Nature/ Science Journals it was wrong in about 95% of cases. So they are setting the bad example

Baker D, Lidster K, Sottomayor A, Amor S. Reproducibility: Research-reporting standards fall short. Nature. 2012 Dec 6;492(7427):41. doi: 10.1038/492041a

After we called them on this, they introduced reporting standards. Did they and their referees learn about the statistics?

So recently we got this figure in a Nature Journal and the work was splashed across the media……….The great new hope.

So we looked as the data

Figure legend. Clinical scores of two independent EAE experiments at d23 post disease induction. Individual scores as well as the mean score of two independent experiments are shown. Control: n=10, vehicle: n=13, xxxxx-345: n=11. Control versus vehicle: P=0.620, control versus xxxxx-345: P=0.017, vehicle versus xxxxx-345 P=0.029.  * indicate P values <0.05 and ** indicate P values <0.005 based on a non-paired Student’s t test. Error bars are s.e.m.

There is a thought in clinical trial studies that you should supply the primary data so it can be re-analysed. Many companies now willingly do this. This probably will occur or science papers too.

So in the figure above they provide primary data. In the drug-treated animals the scores appear to be: 0, 0 ,0, 0.5, 0.5, 2, 2.5, 3, 3.5, 3.5, 3.5 n=11 in vehicle scores appear to be: 0.5, 2.5, 2.5, 2.5, 2,75, 2.75, 3, 3.5, 3.5, 3.5, 3.5, 3.5, 3.5 n=13.

Do a t test drug verses vehicle and you get p=0.029 (as in the legend to the figure above) so all is fine and drug is great. The media go mad… its the next best thing since sliced bread:-)

However, you should not do a t test on this type of data. The assumptions of a t test as that the data is (a) normally distributed. You test this and it passes the test p=0.152,

However, it also assumes that (b) data groups have equal variances (the square of standard deviation). Test for that and it fails P<0.05. So it is not valid to do a t test on this data but importantly it is not valid to do a t test on this data, because the data is not parametric, it is non-parametric.

So do a non-parametric test on the data like the Mann Whitney U test . This has less power to detect differences than a t test.

Do this on the data above and P=0.082………Ooooops.

So now do drug verses untreated as well and this also fails P=0.121, so not even a trend:-)

There is no statistically significant effect. The drug has not worked! So you accept this or do more studies to show if this so called trend is real or not, harder to do in humans, much easier to do in animal studies.

Simple school-boy stuff. All the reviewers need to do is read:

Baker D, Amor S.Publication guidelines for refereeing and reporting on animal use in experimental autoimmune encephalomyelitis. J Neuroimmunol. 2012 ;242(1-2):78-83.

Hopefully, this will get the altimetrics up on the old papers:-)

I suspect many of you won’t be bothered by this post,but if you were pinning your hopes on drug xxxxx-345 then these hopes are being dashed. This type of detective work can not normally be done because we do not get to see the primary data.

This is not a rare example..but a new one to use in my teaching on experimental design 1O1.

About the author



  • Thanks MD.

    I have been trying to explain P-Values and normal distributions to fellow MSers for years….glad you wrote a post on this.

    • I have not mentioned the paper, as the authors will be horrified that they have been used for the example. They will know and any person who knows the literature will be able to find out.

      However they provided raw data. Most studies do not.

      Based on the paper : 0, no clinical signs; 1,limp tail; 2, hind limb weakness; 3, hind limb paralysis; 3.5, euthanized mouse due
      to disease score of more than 3. So in this study in the vehicle/placebo group 6/13 animals were killed and in the drug treated there were 3/11 killed so not much of a prevention (as claimed in the title) when 8/11 got disease.

      Looking at the data it looks like it either worked (low score) or it didn't (High score) so it may have been a chance event that 3 animals did not get EAE in one group. The other interesting thing are the scores not only are there 2.5 but 2.75. This is not explained in the methods so we have no idea how this occurs.

      We have a half score in our EAE system for not quite a 3 would be a 2.5. This helps with the statistics because it (Mann Whitney) is based on rank rather than actual value from lowest to highest so in the example it would not matter if the figure was 2.7 or 2.8 or 2.75 because in the other group there is nothing between 2.5 and 3 so there are 3 scores in that group however how one gets a 2.75 is not explained. It suggests a massive scale not mentioned in the methods so how one could repeat the work I do not know
      A p value is called a probability value p=0.05 means if you did experiment 100 times there would be a chance that this happens 5 times P=0.01 if you did experiment 100 times by chance this would occur once P=0.001 means you would have to do the experiment a thousand times for there the result to occur by chance. Although possible it is unlikely so you accept that the result you see is not due to chance. Hope that helps.
